Gap Height Overall Width Visible Width Movement Loading Capacity Length
30 mm 15 / 28 mm 127 mm 47 mm ± 2 mm N/A 3 m
Gap Height Overall Width Visible Width Movement Loading Capacity Length
30 mm 47 / 57 mm 120 mm 38 mm +10 / -6 mm N/A 3 m
Gap Height Overall Width Visible Width Movement Loading Capacity Length
30 mm 15 mm 97 mm 32 mm ± 5 mm N/A 3 m
Gap Height Overall Width Visible Width Movement Loading Capacity Length
30 mm 16 mm 130 mm 130 mm +40 / -30 mm N/A 3 m
